ir-X
|
|
|
Specifications:
Size: |
1/2 ISA Card Slot |
Power: |
200ma. @5VDC |
I/O:
|
IR:
2 Output
Zones (3.5mm Mono)
1 Input Zone
(3.5mm Stereo)
8k bit
Command Data Storage
Variable
Modulation Frequency
Variable
Sample Rate
X-10:
TW-523 Ready
(RJ-11)
256 (512)
Two-way Commands
Analog:
2 Input
Channels (3.5mm Stereo)
0-2.5V Inputs
8-Bit
Resolution
PC: I/O Addressed @ 280
Hex
Uses 4 I/O
Port Addresses
Available
Interrupts 3,4,5,7,9 |
|
|
$99
|
_____________________________________________
Features:
The Intelligent
X-10 and learning IR transceiver, ir-X, is
an inexpensive entry-level I/O for PC based
control programs. The ir-X offers 256
channels (512 total commands) of two-way X-10. An
ISA interrupt is available to signal that an X-10
command has been received. The on-board
microprocessor executes all timing and polling to
off-load the PC.
I/O Port Drivers:
DriverLINX
-- I/O Port
Utility (DLL) for Windows 95/98/NT
TinyPort 2.0
-- I/O Port
Utility (DLL) for Windows NT (Shareware)
|
|
